Features

• Mix & match shades on a 5-channel remote
• Multiple channels can be selected and controlled simultaneously
• Control multiple devices in the same channel
• Pairs directly with the shade • Limit-setting fully supported
• Securely flush mounts to a wall with or without a junction box
• Compatible with standard decora cover plates
• Optionally functions as a hand held remote

---

Pairing your remote

• Make sure to remove the plastic battery saver

• Using the remote that came with your Niño shades, follow the steps below

---

Battery Replacement

 .

• Separate the remote covers using a screw driver.
• Once the back cover has been removed, use a screwdriver to assist in removing the battery. Ensure that the circuit board is not damaged during this process.
• The replacement battery should have its label facing up. Check that the replacement battery has not been used or stored for more than a year. The battery lifespan will be reduced if it is stored for an extended period of time.

---

Technical Specifications

• Battery type Radio - CR2430 (3V)
• Frequency - 433.92 MHz
• Operating Temperature - 14°F to 122°F

---

For issues, contact Screen Innovations:
Phone: [phone] Option 3
Website: www.screeninnovations.com
